توضیحات تکمیلی
| کانال | 8 کانال |
|---|---|
| تشخیص چهره و تجزیه و تحلیل | Face picture comparison, face picture search (2-ch face picture comparison alarm for HD analog camera) |
| کتابخانه تصویر چهره | Up to 16 face picture libraries |
| تجزیه و تحلیل انسان و وسیله نقلیه | Deep learning-based motion detection 2.0 is enabled by default for all analog channels, it can classify human and vehicle, and extremely reduce false alarms caused by objects like leaves and lights;, Quick search by object or event type is supported; |
| تجزیه و تحلیل انسان / وسیله نقلیه | Up to 4-ch Note: Face picture comparison, motion detection 2.0 and perimeter protection cannot be enabled at the same time. Enable one function will make the other two unavailable. |
| ورودی تصویر IP | 4ch (up to 12-ch), Up to 6 MP resolution |
| ورودی ویدئو آنالوگ | 8ch BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection |
| خروجی VGA | 1ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz HDMI/VGA simultaneous output |
| پخش همزمان | 8ch |
| ورودی HDTVI | 3K(2960 x 1665)@25/20 fps, 3K(3328×1504)@20fps,2K(2304×1296)@20fps,5 MP(2560 × 1944)@20 fps, 4 MP(2560 × 1440)@25/30 fps,1080P@25/30 fps, 720P@25/30fps |
| ورودی AHD | 5MP(2560 × 1944)@20 fps, 4 MP(2560 × 1440)@25/30 fps,1080P@25/30 fps, 720P@25/30fps |
| ورودی HDCVI | 3K(2880×1620)@25fps, 5MP(2592 × 1944)@20 fps, 4MP(2560 × 1440)@25/30 fps,1080P@25/30 fps, 720P@25/30fps |
| خروجی صدا | 1ch, RCA (Linear, 1 KΩ) |
| ورودی صوتی | 8ch, RCA (2.0 Vp-p, 1 KΩ), 8-ch via coaxial cable;4-ch, RCA (2.0 Vp-p, 1 KΩ), 8-ch via coaxial cable;1-ch (up to 8-ch is optional), RCA (2.0 Vp-p, 1 KΩ),8-ch via coaxial cable |
| صدا دو طرفه | 1ch, RCA (2.0 Vp-p, 1 KΩ, using the audio input) |
| خروجی HDMI | 1ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, HDMI/VGA simultaneous output |
| ورودی CVBS | PAL/NTSC |
| خروجی CVBS | 1ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480 |
| فشرده سازی ویدیو | H.265 Pro+/H.265 Pro/H.265/H.264+/H.264 |
| وضوح رمزگذاری | When 1080p Lite mode is not enabled: 3K lite/5 MP lite/4 MP lite/1080p/720p/VGA/WD1/4CIF/CIF; When 1080p Lite mode is enabled: 3K lite/5 MP lite/4 MP lite/1080p lite/720p lite/VGA/WD1/4CIF/CIF |
| نرخ فریم | (N) Sub-stream: WD1/4CIF@12fps; CIF@25fps (P)/30fps (N), 720p/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N) When 1080p Lite mode enabled: 3K lite/5 MP lite@12fps;4 MP lite@15fps;1080p lite/720p lite/VGA/WD1/4CIF/CIF@25fps (P)/30fps, For 1080p stream access: 1080p/720p@15fps; VGA/WD1/4CIF/CIF@25fps (P)/30fps (N) For 720p stream access:, For 4 MP stream access: 4 MP lite/1080p@15fps;720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N), For 5 MP stream access: 5 MP lite@12fps;4 MP lite/1080p@15fps;720p/WD1/4CIF/VGA/CIF@20fps, Main stream: When 1080p Lite mode not enabled: For 3K stream access: 3K lite@12fps;4 MP lite/1080p@15fps;720p/WD1/4CIF/VGA/CIF@20fps |
| میزان بیت ویدیو | 32Kbps to 6 Mbps |
| جریان دوگانه | Support main stream or sub stream |
| نوع جریان | Video, Video & Audio |
| فشرده سازی صدا | G.711u |
| میزان بیت صدا | 64Kbps |
| پروتکل شبکه | TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF, ISUP |
| رابط شبکه | 1RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface |
| اتصال از راه دور | 64 |
| پهنای باند کل | 96Mbps |
| Wi-Fi | Wi-Fi Connectable to Wi-Fi network by Wi-Fi dongle through USB interface |
| سریال رابط | RS-485 (half-duplex) |
| SATA | 1 SATA interface, up to 10 TB capacity for each disk |
| زنگ ورود/خارج | 8/4;N/A (optional to support);4/1 |
| رابط USB | Front panel: 1 × USB 2.0; Rear panel: 1 × USB 2.0 |
| منبع تغذیه | 12VDC, 1.5 A |
| مصرف | (without HDD), 18W≥ |
| دمای کاری | 10°C to 55 °C (14 °F to 131 °F)- |
| رطوبت کاری | 10%to 90% |
| ابعاد (W × H × D) | (319×236×48 mm )(12.6 × 9.3 × 1.9 inch) |
| وزن | 1.78kg (3.9 lb.)≥ |
